Callus induction and regeneration via shoot tips of Dendrocalamus hamiltonii
SpringerPlus volume 5, Article number: 1799 (2016)
By using shoot tips as explants, various media and culture conditions for callus induction and proliferation, shoot differentiation, root induction and plantlet transplantation to develop an efficient and reliable regeneration system with Dendrocalamus hamiltonii were tested. Murashige and Skoog (MS) medium supplemented with 3 mg/l 2, 4-dichlorophenoxyacetic acid, 1 mg/l benzyladenine (BA), 500 mg/l glutamine, 500 mg/l proline, and 500 mg/l casein hydrolysate yielded the best rates of callus induction and granular-compact callus induction. MS medium supplemented with 1 mg/l BA, 0.3 mg/l kinetin and 0.3 mg/l naphthaleneacetic acid conferred the highest differentiation rate of calli. The maximum rooting rate was obtained in 1/2 MS medium supplemented with 3 mg/l indole-3-butyric acid, and the roots were long and thick. All hardened plantlets survived after transfer to an equal ratio mixture of peat, vermiculite and perlite. The regeneration system of D. hamiltonii developed is efficient and provides a useful tool for genetic transformation in bamboo species.
Bamboos are the members of the grass family, including more than 88 genera and 1400 species worldwide. Because of rapid growth, high output, highly maintaining soil and water, and other values, they are economically, socially and ecologically important in China (Jiang 2002). Dendrocalamus hamiltonii is one of the three most important bamboo species with sweet shoots in the world and is cultivated for its shoots and timber in Xishuangbanna and Puer, Yunnan province, in China.
Regeneration from calli is a useful approach for the genetic improvement of bamboo. Regenerated plantlets in bamboo were obtained for the first time from the zygotic embryos of Bambusa arundinacea (Mehta et al. 1982). Then the mature seeds of D. strictus, D. latiflorus, Bambusa multiplex and D. hamiltonii (Rao et al. 1985; Yeh and Chang 1987; Yuan et al. 2009; Zhang et al. 2010), and young inflorescences of B. oldhami, B. beecheyana var. beecheyana and D. latiflorus (Yeh and Chang 1986a, b; Qiao et al. 2013) were used as explants for callus induction and regeneration.
The inflorescences, embryos and seeds of the bamboos are good resources for explants, but they are difficult to obtain because bamboos rarely blossom and bear fruit. However, shoot tips are available at any time and easy to obtain. Thus, shoot tips can be used as explants to create regenerated plantlets through callus induction and regeneration.
In this study, the effects of different media and different combinations of 2, 4-dichlorophenoxyacetic acid (2, 4-D), benzyladenine (BA), indole-3-butyricacid (IBA), and organic additives on callus induction from shoot tips of D. hamiltonii were determined. The orthogonal test design [L9 (34)] was used to investigate the effects of BA, α-naphthaleneacetic acid (NAA), and kinetin (KT) on shoot differentiation. An efficient regeneration system was developed that can be used for genetic improvement of bamboo.
Plant materials and tissue culture condition
Dendrocalamus hamiltonii (Poaceae, subfamily bambusoideae) was obtained from Xishuangbanna, Yunnan Province, P. R. China. Shoots were collected from the plants cultivated in greenhouse of Zhejiang Agriculture and Forestry University in August. For surface disinfection, the shoots were first washed with running tap water for about 1 h, then immersed in 75 % (v/v) ethanol for 30 s, followed by 1 % (v/v) sodium hypochloride (NaClO) vacuum infiltration for 15 min. The shoots were separated and the shoot-tips were inoculated on tissue culture media (Fig. 1a) after the shoots were washed with autoclaved distilled water six times. The callus induction and subculture were conducted in the dark at 25 ± 2 °C, and the shoot differentiation induction and root induction were performed under a 16/8-h light/dark photoperiod with continuous illumination of 2400 lx at 25 ± 2 °C.
Callus induction and subculture
The different concentrations of 2, 4-D (0, 0.1, 0.3, 1, 3 and 10 mg/l), BA (0, 1, 2 and 4 mg/l), organic additives [500 mg/l casein hydrolysate (CH), 500 mg/l proline (Pro), 500 mg/l glutamine (Gln), 30 mg/l adenine sulfate (Ads), 500 mg/l yeast extract (YE), and 500 mg/l CH + 500 mg/l Pro + 500 mg/l Gln)], 30 g/l sucrose and 8 g/l Type A agar were used to select the optimal medium for callus induction. The pH of medium was adjusted to 5.7. Compact and granular calli were subcultured on a new medium every 4 weeks.
Adventitious shoot differentiation induction
After 2–3 subcultures, creamy-yellow and compact calli were transferred to MS medium supplemented with 30 g/l sucrose, 3 g/l gelrite and different concentrations of plant growth regulators (PGRs), including BA (1, 2 and 4 mg/l), KT (0.1, 0.3 and 1 mg/l) and NAA (0.1, 0.3 and 1 mg/l) in an orthogonal array [L9 (34)], which is a time- and cost-saving strategy to investigate the main effects in order of priority (Ross 1996; Rao et al. 2008). The pH of the medium was adjusted to 5.7. The differentiation rate and shoot growth condition were recorded 4 weeks later.
Rooting and transplantation
After 4 weeks’ differentiation, the differentiated shoots (length 3 cm) were induced on the 1/2 MS medium supplemented with 30 g/l sucrose, 3 g/l gelrite and IBA in different concentrations (0, 1, 3 and 10 mg/l) for 4 weeks. Plantlets that rooted well were transferred to a cultivation chamber (20000 lx) for hardening in the greenhouse. The survival rate was recorded after 4 weeks.
All treatments were repeated three times. ANOVA involved use of SPSS v15 (SPSS Inc., Chicago, IL). The differences between treatments were evaluated by Duncan’s multiple range test (Duncan 1955). Figures were created by using SigmaPlot v8.0, and DPS v6.55 was used to analyze orthogonal test.
Effect of basal media and plant growth regulators on callus induction
Calli appeared from the shoot tips on the media supplemented with 3 mg/l 2, 4-D at about 2 weeks after inoculation (Fig. 1b) and grew well 1 month later. The rate of callus induction on MS medium was 94.60 % and significantly higher than that on B5, Nitsch and White media but did not differ from that on 1/2 MS medium (Fig. 2). Most of the calli grown on 1/2 MS medium were loose lumps with long buds or had a fibrous surface and were unable to proliferate and differentiate, whereas most (58.27 %) induced on MS medium were compact and granular and were able to proliferate (Fig. 1c, d). MS medium was the best for callus induction from shoot tips of D. hamiltonii.
2, 4-D is crucial for callus induction, but different concentrations may be required for different explants. Therefore, the effects of the different concentrations of 2, 4-D on callus formation were determined. The rates of callus induction (86.50 %) and compact and granular callus (61.00 %) were all elevated with increasing 2,4-D concentrations but were decreased with 2,4-D at 10 mg/l (Fig. 3). The data suggest that 3 mg/l was the optimal 2, 4-D concentration for callus induction.
Different concentrations of BA combined with 3 mg/l 2, 4-D were used to determine the effect of BA on callus formation. The rate of callus induction was higher without BA (88.35 %) than with any BA concentrations tested (58.35–68.35 %), but the rate of compact and granular calli was higher with 1 mg/l BA (66.94 %) than with the other treatments (22.29–60.50 %) (Fig. 4). Therefore, 1 mg/l BA was the best for producing high-quality calli.
The effects of different organic additives on callus formation were also determined. Organic additives except yeast extraction increased the rate of callus induction (70.00–86.70 %) as compared with the control (61.67 %) (Fig. 5). As well, the combination of CH, Pro and Gln yielded the highest rate of compact callus induction (63.30 %), which significantly differed from that with other treatments (16.67–60.00 %).
Effect of plant growth regulators on shoot differentiation induction
The effect of PGRs on shoot differentiation and development was shown in Table 1. The combination of 1 mg/l BA, 0.3 mg/l KT and 0.3 mg/l NAA yielded better-quality shoots and the highest rate of shoot differentiation (51.65 %) than other treatments (Fig. 1d–g). The effect of individual factors on shoot differentiation rate decreased in the order of NAA > KT > BA but not significantly (Table 2).
Rooting and transplantation
The rate of root induction and number of roots were both increased with increasing IBA concentration (Table 3). However, 10 mg/l IBA caused swollen roots, and roots induced by 3 mg/l IBA were stout (Fig. 1h). These data demonstrate that 3 mg/l IBA was the optimal concentration for rooting induction on 1/2 MS medium.
The survival rate of hardening plantlets was 100 % after they were transferred to an equal ratio mixture of peat, vermiculite and perlite and grew well in the greenhouse (Fig. 1i).
Genetically improving bamboo species by using traditional sexual crossbreeding is difficult because bamboo takes many years to blossom and then dies. A transgenic approach provides a useful tool for genetically breeding bamboo. A stable and efficient regeneration system is important for genetic improvement. A regeneration system involving D. hamiltonii with zygotic embryos in mature seeds, which are difficult to obtain, was developed previously (Zhang et al. 2010). In this study, shoot tips that are available all the time were used as explants, which made the regeneration system be more convenient and feasible.
Basal medium is an important factor to induce callus formation in plants. Different species may require different media for callus induction. For instance, B5 medium was used for culture of legumes and woody plants that are sensitive to ammonium salt poisoning (Ma and Zhang 2007). The regeneration of bamboos via explants such as node segments (Godbole et al. 2002) and seeds (Woods et al. 1992) required MS and B5 media, respectively. Moreover, Nitsch basal medium was also used to induce somatic embryogenesis (Martinelli et al. 2015; Morgana et al. 2015). In this paper, MS, B5, Nitsch, White and 1/2 MS media were tested for calli formation, and MS was the best basal medium for the regeneration system in D. hamiltonii.
2, 4-D was essential to callus induction in bamboo, but a high concentration reduced the capacity of calli to differentiate (Huang et al. 1989; Enric et al. 2000). In bamboo, an optimal concentration of 2, 4-D depends on the species (Saxena and Dhawan 1999; Lin et al. 2003; Woods et al. 1992). In this study, 3 mg/l 2, 4-D was the best concentration to induce calli, which were compact and granular and proliferate rapidly.
The appropriate concentration of BA promoted callus induction and differentiation in many plant species (Liu et al. 2009; Liu and Shi 1996). In addition, the combination of 2,4-D and BA was efficient in inducing compact callus and plant regeneration of many species (Wang et al. 2007; Siddique and Islam 2015). In this study, BA played a role in improving bamboo callus induction and proliferation.
Organic additives were used to increase nutrition sources and improve the quality of calli in tissue culture (Staden and Drewes 1975; Dix and Staden 1982; Qiao et al. 2013). Coconut milk, honey, banana extract, yeast extract, malt extract, hydrolyzed casein, and various amino acids individually or in combination played a significant role in reducing callus browning, adjusting osmosis, and producing secondary (Kim et al. 2009; Indrayanto et al. 1995; Armstrong and Green 1984). In this paper, the combination of 500 mg/l CH, 500 mg/l Pro and 500 mg/l Gln greatly promoted callus induction in D. hamiltonii.
The stage of callus differentiation is a key to establishing a regeneration system. Organ differentiation was mainly determined by the balance of hormones, which is changed by adjusting appropriate exogenous cytokinin and auxin levels (Shirin and Rana 2007). A high concentration of BA might cause plant growth inhibition or have toxic effects on bamboo growth. A low concentration of KT played an active role in differentiation, whereas a high concentration could cause bud browning and unhealthy plants (Nadgir et al. 1984; Chambers et al. 1991). In the study, calli subcultured in MS medium supplemented with 1 mg/l BA, 0.3 mg/l KT, and 0.3 mg/l NAA produced fascicled shoots that showed vigorous budding and elongation.
A medium supplemented with a certain concentration of an auxin was found conducive to bamboo rooting (Huang and Murashige 1983). In this paper, with 3 mg/l IBA, the rate of root induction peaked (95 %), and each plantlet generated 7–8 roots that grew well with the supplement.
A stable and efficient regeneration system in D. hamiltonii was developed by using easily obtained shoot tips as explants, which provides a useful tool for genetic transformation in bamboo species.
- MS medium:
Murashige and Skoog medium
- 2, 4-D:
2, 4-dichlorophenoxyacetic acid
plant growth regulators
Armstrong CL, Green CE (1984) Establishment and maintenance of friable, embryogenic maize callus and the involvement of L-proline. Planta 164:207–214
Chambers SM, Heuch JHR, Pirrie A (1991) Micropropagation and in vitro flowering of bamboo Dendrocalamus hamiltonii Munro. Plant Cell Tissue Org Cult 27:45–48
Dix L, Staden JV (1982) Auxin and gibberellin-like substances in coconut milk and malt extract. Plant Cell Tissue Org Cult 1(1):239–246
Duncan DB (1955) Multiple range and multiple F test. Biometrics 11:1–42
Enric B, Calpe J, Casado J (2000) Mineralization of 2, 4-D by advanced electrochemical oxidation processes. Water Res 34(8):2253–2262
Gamborg O, Miller R, Ojima K (1968) Nutrient requirements of suspension cultures of soybean root cells. Exp Cell Res 150:151–158
Godbole S, Sood A, Thakur R, Sharma M, Ahuja PS (2002) Somatic embryogenesis and its conversion into plantlets in a multipurpose bamboo, Dendrocalamus hamiltonii Nees et Arn. Ex Munro Curr Sci 83:885–889
Huang LC, Murashige T (1983) Tissue culture investigations of bamboo. Bot Bull Acad Sin 24:31–52
Huang LC, Huang BL, Chen WL (1989) Tissue culture investigations of bamboo IV: organogenesis leading to adventitious shoots and plants in excised shoot apices. Environ Exp Bot 29:307–315
Indrayanto G, Erawati T, Santosa MH (1995) Effect of l-arginine, casein hydrolysate, banana powder and sucrose on growth and solasodine production in shoot cultures of Solanum laciniatum. Plant Cell Tissue Org Cult 43:237–240
Jiang ZH (2002) Bamboo and rattan in the world. Liaoning Science and Technology Press, Shenyang, pp 3–4
Kim YW, Newton R, Frampton J, Han KH (2009) Embryogenic tissue initiation and somatic embryogenesis in Fraser fir (Abies fraseir[Pursh]Poir.). In Vitro Cell Dev Plant 45:400–406
Lin CS, Lin CC, Chang WC (2003) Effect of thidiazuron on vegetative tissue-derived somatic embryogenesis and flowering of bamboo Bambusa edulis. Plant Cell Tissue Org Cult 76:75–82
Liu JH, Shi JC (1996) Studies on selection of valuable somaclonal mutants in silage maize. Acta Bot Sin 38(10):839–842
Liu L, Fan XL, Zhang JW (2009) Long-term cultured callus and the effect factor of high-frequency plantlet regeneration and somatic embryogenesis maintenance in Zoysia japonica. In Vitro Cell Dev Plant 45:673–680
Ma JL, Zhang B (2007) Effect of medium, sucrose and exogenous hormones on the callus induction rate in alfalfa anther culture. Xinjiang Agric Sci 44(6):839–844
Martinelli L, Gribaudo I, Bertoldi D, Candioli E, Poletti V (2015) High efficiency somatic embryogenesis and plant germination in grapevine cultivars Chardonnay and Brachetto a grappolo lungo. VITIS J Grap Res 40(3):111–115
Mehta U, Rao IVR, Ram HYM (1982) Somatic embryogenesis in bamboo. In: Proceedings of the 5th international congress on plant tissue cell culture, pp 109–110
Morgana C, Di Lorenzo R, Carimi F (2015) Somatic embryogenesis of Vitis vinifera L.(cv. Sugraone) from stigma and style culture. VITIS J Grap Res 43(4):169–173
Murashige T, Skoog F (1962) A revised medium for rapid growth and bioassay with tobacco tissue culture. Physiol Plant 15:473–497
Nadgir AL, Phadke CH, Gupta PK, Parsharmi VA, Nair S, Mascarenhas AF (1984) Rapid multiplication of bamboo by tissue culture. Silvae Gen 33:219–233
Nitsch JP (1951) Growth and development in vitro of excised ovaries. Am J Bot 38(7):566–577
Qiao GR, Li HY, Liu MY (2013) Callus induction and plant regeneration from anthers of Dendrocalamus latiflorus Munro. Vitro Cell Dev Plant 49(4):375–382
Rao IU, Rao IVR, Narang V (1985) Somatic embryogenesis and regeneration of plants in the bamboo Dendrocalamus strictus. Plant Cell Rep 4:191–194
Rao RS, Kumar CG, Prakasham RS, Hobbs PJ (2008) The Taguchi methodology as a statistical tool for biotechnological applications: A critical appraisal. Biotech J 3:510–523
Ross PJ (1996) Taguchi techniques for quality engineering: loss function, orthogonal experiments, parameter and tolerance design, vol 2. McGraw-Hill, New York, pp 329–337
Saxena S, Dhawan V (1999) Regeneration and large-scale propagation of bamboo (Dendrocalamus strictus Nees) through somatic embryogenesis. Plant Cell Rep 18:438–443
Shirin F, Rana PK (2007) In vitro plantlet regeneration from nodal explants of field-grown culms in Bambusa glaucescens Willd. Plant Biotechnol Rep 1:141–147
Siddique AB, Islam SM (2015) Effect of light and dark on callus induction and regeneration in tobacco (Nicotiana tabacum L.). Bangladesh J Bot 44(4):643–651
Staden JV, Drewes SE (1975) Isolation and identification of zeatin from malt extract. Plant Sci Lett 4:391–394
Wang WG, Wang SH, Wu XA, Jin XY, Chen F (2007) High frequency plantlet regeneration from callus and artificial seed production of rock plant Pogonatherum paniceum (Lam.) Hack.(Poaceae). Sci Hortic 113(2):196–201
White PR (1943) A handbook of plant tissue culture. Soil Sci 56(2):151–158
Woods SH, Phillips GC, Woods JE, Collins GB (1992) Somatic embryogenesis and plant regeneration from zygotic embryo explants in Mexican weeping bamboo, Otatea acuminata aztecorum. Plant Cell Rep 11:257–261
Yeh M, Chang WC (1986a) Plant regeneration through somatic embryogenesis in callus culture of green bamboo (Bambusa oldhamii Munro). Theor Appl Genet 73:61–163
Yeh M, Chang WC (1986b) Somatic embryogenesis and subsequent plant regeneration from inflorescence callus of Bambusa beecheyana Munro var. beecheyana. Plant Cell Rep 5:409–411
Yeh M, Chang WC (1987) Plant regeneration via somatic embryogenesis in mature embryo-derived callus culture of Sinocalamus latiflora (Munro) McClure. Plant Sci 51:93–96
Yuan JL, Gu XP, Li LB, Yue JJ, Yao N, Guo GP (2009) Induction and plantlet regeneration of Bambusa multiplex. Sci Silvae Sin 3:35–40
Zhang N, Fang W, Shi Y, Liu QQ, Yang HY, Gui RY, Lin XC (2010) Somatic embryogenesis and organogenesis in Dendrocalamus hamiltonii. Plant Cell Tissue Org Cult 103(3):325–332
XL conceived and designed the research. LZ, QZ, FZ, HY and XW conducted the experiments. LZ and QZ carried out the statistical analysis, and wrote the manuscript. All authors read and approved the final manuscript.
This study was supported by the National Natural Science Foundation of China (Grant No. 31270677), the Natural Science Foundation of Zhejiang Province (Grant No. Z3100366), and the China Scholarship Council to X Lin.
The authors declare that they have no competing interests.
Qiaolu Zang and Ling Zhou contributed equally to this work
