Open Access

Dramatic mitigation of bone pain after phosphorus replacement therapy in a subject with FGF23-related hypophosphatemic osteomalacia

  • Fuminori Tatsumi1,
  • Megumi Horiya1,
  • Akihito Tanabe1,
  • Momoyo Nishioka1,
  • Yoshiro Fushimi1,
  • Junpei Sanada1,
  • Yurie Hirata1,
  • Shintaro Irie1,
  • Tomoe Kinoshita1,
  • Shinji Kamei1,
  • Masashi Shimoda1,
  • Tomoatsu Mune1,
  • Kohei Kaku1 and
  • Hideaki Kaneto1Email author
SpringerPlus20165:1904

https://doi.org/10.1186/s40064-016-3602-6

Received: 8 May 2016

Accepted: 25 October 2016

Published: 2 November 2016

Abstract

Introduction

Fibroblast growth factor 23 (FGF23) is secreted from bone and suppresses the absorption of phosphorus in renal proximal tubule and in intestinal tract. Therefore, the increase of serum FGF23 levels leads to hypophosphatemic situations. Tumor-induced osteomalacia is often induced by various tumors, but it is often difficult to identify the localization of tumor, because most of the FGF23-producing tumors are small and could be observed in any part of the body.

Case description

Here we report a case of elderly female subject with FGF23-related hypophosphatemic osteomalacia who repeatedly experienced severe bone pain and fragility fracture in various parts of the body. Although we failed to identify the localization of tumor in this subject even with various examination, after starting phosphorus replacement therapy with relatively small amounts of calcium phosphate (1.5 g/day) (phosphorus content: 270 mg), hypophosphatemia was ameliorated and repeated bone pain was dramatically mitigated without any surgical operation.

Discussion and Evaluation

Even when we fail to identify the localization of tumor in subjects with FGF23-related hypophosphatemic osteomalacia, phosphorus replacement therapy for hypophosphatemia could reduce the bone pain.

Conclusions

We should be aware of the possibility that phosphorus replacement therapy exert marked beneficial effects for the reduction of bone pain in subjects with FGF23-related hypophosphatemic osteomalacia even when we fail to identify tumor localization.

Keywords

FGF23 Phosphorus Hypophosphatemic osteomalacia Bone pain Fragility fracture Phosphorus replacement

Background

It is known that fibroblast growth factor 23 (FGF23) is secreted from bone and suppresses the absorption of phosphorus in renal proximal tubule and in intestinal tract. Therefore, the increase of serum FGF23 levels leads to hypophosphatemic situations (Bergwitz et al. 2011; Jonsson et al. 2003; Yu and White 2005). Indeed, FGF23 is an etiology factor of autosomal dominant hypophosphatemic rickets (ADHR) and tumor-induced osteomalacia (Chong et al. 2011, 2013). Tumor-induced osteomalacia is often induced by various tumors such as phosphaturic mesenchymal tumor and ovarian cancer. It is known that FDG-PET/CT and measurement of FGF23 levels in limb with selective venous sampling are useful to estimate the tumor localization and that, if possible, the resection of tumor is the best therapy for the disease. On the other hand, it is often difficult to identify the localization of tumor, since most of the FGF23-producing tumors are benign and small, and these tumors have potential to occur anywhere in the body. Here we report a case of elderly female subject with FGF23-related hypophosphatemic osteomalacia who often experienced severe bone pain and fragility fracture in various parts of the body. Since we failed to identify the localization of tumor in this subject even after various kinds of evaluation, we started phosphorus replacement therapy for the treatment of hypophosphatemia. As the results, repeated bone pain in this subject was dramatically mitigated after the amelioration of hypophosphatemia by phosphorus replacement therapy.

Case presentation

In 2014, a 75-year-old female was hospitalized in our institution for the careful examination of whole body bone pain and fragility fracture. In 2012, she experienced fracture in proximal end of left tibia and left foot joint. At that time, bone density was as follows: lumbar spine YAM, 79%; left femur YAM, 58%. She was diagnosed as osteoporosis and started taking PTH formulation in local clinic. Furthermore, in 2013, she experienced femur fracture on both sides and multiple rib fracture. At that time, bone density was as follows: lumbar spine YAM, 66%; left femur YAM, 59%. After then, she started taking bisphosphonates. In spite of such therapy, in 2014, she experienced fracture in various parts of the body such as left pubis and left olecranon. After then, she started taking active vitamin D preparations. Finally, she was hospitalized in our institution for the careful examination of such frequent fracture in various parts of body.

On admission (August, 2014), her height was 142.5 cm and body weight was 44.7 kg (body mass index: 22.0 kg/m2). Although her previous height was unknown, it seemed that her height became shorter apparently due to scoliosis and vertebral compression fracture. Blood pressure was 132/84 mmHg and heart rate was 80 bpm. Body temperature was 36.9 °C. Her consciousness was clear, but she was under bedrest state all day due to severe bone pain throughout the whole body and she had a lot of difficulties even when she tried to turn over in bed. Although there was thoracic deformity, respiratory and heart sound was normal. In addition, there was no abnormality in abdomen. Table 1 shows the clinical characteristics of this subject on admission. Hypophosphatemia (1.5 mg/dL) and hypocalcemia (8.1 mg/dL) (8.3 mg/dL after correction with serum albumin level) were observed. ALP level was high (855 U/L), and BAP (bone-type ALP) level was as high as 88.2 μg/L (normal range 3.8–22.6 μg/L). Serum FGF23 level was also as high as 275 pg/mL (normal range: 10–50 pg/mL). As shown in Table 1, various tumor marker levels all of which we measured were within normal range except for the slight increase of SCC level. As shown in Fig. 1a, in chest X-ray, there were remnants of multiple rib fracture, marked deformation of the thorax, scoliosis and cardiomegaly. In bone scintigraphy, abnormal accumulation was observed in ribs on both sides and limb joints (Fig. 1b). These are the findings after multiple fractures in the body. In computer tomography (CT), there was sciatic fracture on both sides, multiple rib fracture, vertebral compression fracture and marked deformation in the thorax (Fig. 1c). Neoplastic lesion was not observed in bone and soft tissues. There was localized frosted glass shade in upper right lung field. In FDG-PET/CT, there was no abnormal accumulation in the whole body, although slight accumulation was observed in thoracolumbar spine and upper limb joint which was presumably due to arthritis (Fig. 1d). Furthermore, we performed selective venous sampling and measured serum FGF23 levels in various parts of limb, but there was no marked difference in FGF23 levels among various parts of limb as follows: elbow vein, 331 pg/mL (left), 326 pg/mL (right), femoral vein, 299 pg/mL (left), 295 pg/mL (right).
Table 1

Clinical characteristics of this subject on admission

WBC

5350/μL

CK

38 U/L

Whole PTH

25.6 pg/mL

Neu

66.6%

CRP

0.08 mg/dL

PTHrP

≤1.0 pmol/L

Lym

25.9%

PBS

83 mg/dL

1,25(OH)2D3

38.9 pg/mL

Mon

5.1%

HbA1c

5.3%

25(OH)D

7 ng/mL

Eo

2.2%

LDL-chol

95 mg/dL

ACTH

27.8 pg/mL

Bas

0.2%

HDL-chol

41 mg/dL

Cortisol

6.6 μg/dL

RBC

405 × 104/μL

TG

118 mg/dL

DHEA-S

74 μg/dL

Hb

12.8/μL

TSH

0.66 μU/mL

FGF23

275 pg/mL

Ht

37.7/μL

FT4

1.05 ng/dL

Osteocalcin

7.6 ng/mL

plt

18.5 × 104/μL

IgG

931 mg/dL

Serum NTx

22.8 nmol BCE/L

TP

6.1 g/dL

IgA

141.6 mg/dL

TRACP-5b

357 mU/dL

Alb

3.8 g/dL

IgM

48.7 mg/dL

BAP

88.2 μg/L

T-bil

0.3 mg/dL

Na

141 mEq/L

ucOC

1.93 ng/mL

AST

22 U/L

K

3.9 mEq/L

Intact PINP

96.5 μg/L

ALT

17 U/L

IP

1.5 mg/dL

CEA

1.5 ng/mL

γGTP

50 U/L

Ca

8.1 mg/dL

CA19-9

7.9 U/mL

ALP

855 U/L

Corrected Ca

8.3 mg/dL

CA125

8 U/mL

LDH

166 U/L

Urinary Cre

21 mg/dL

SLX

20.0 U/mL

ChE

295 U/L

Urinary P

5.9 mg/dL

AFP

2.4 ng/mL

Crn

0.37 mg/dL

Urinary Ca

9.9 mg/dL

SCC

1.9 ng/mL

BUN

11 mg/dL

FECa

4.46%

CYFRA

1.8 ng/mL

UA

4.8 mg/dL

Tmp/GFR

1.40 mg/dL

ProGRP

45.6 pg/mL

Fig. 1

a Chest X-ray. There are remnants of multiple rib fracture, marked deformation of the thorax, scoliosis and cardiomegaly. b Bone scintigraphy. Abnormal accumulation is observed in ribs on both sides, limb joints. These are the findings after multiple fractures in the body. c Computer tomography (CT). There is sciatic fracture on both sides, multiple rib fracture, vertebral compression fracture and marked deformation in the thorax. Neoplastic lesion is not observed in bone and soft tissues. There is localized frosted glass shade in upper right lung field. d FDG-PET/CT. There is no abnormal accumulation in the whole body, although slight accumulation is observed in thoracolumbar spine and upper limb joint probably due to arthritis

Since we failed to identify the localization of tumor in this subject even with various kind of measurements, we had no choice but to depend on drug therapy and started phosphorus replacement therapy for hypophosphatemia. On September, 2014, we started using calcium phosphate for the treatment of hypophosphatemia in addition to active vitamin D preparations. We used relatively small amounts of calcium phosphate (1.5 g/day) (phosphorus content: 270 mg) in order to avoid the appearance of some side effects in this elderly subject. Such treatment, however, exerted marked beneficial effects in this subject. Hypophosphatemia was significantly ameliorated from 1.5 to 2.5 mg/dL. After discharge from our institution, serum phosphorus levels were within normal range and there was no recurrence of hypophosphatemia with the same amounts of calcium phosphate (1.5 g/day). Serum phosphorus level on March and July in 2015 was 2.5 and 2.7 mg/dL, respectively. Serum calcium levels were also within normal range and there was no recurrence of hypocalcemia. Serum calcium level on March and July in 2015 was 9.1 mg/dL (8.9 mg/dL after correction with serum albumin level) and 9.4 mg/dL (9.1 mg/dL after the correction), respectively. ALP level gradually decreased after the discharge, but it did not reach the normal range. ALP levels on March and July in 2015 was 654 U/L and 591 U/L, respectively. Since this patient hesitated to have an examination about bone density after starting calcium phosphate, we failed to obtain the follow-up data about this point after starting the therapy. We think, however, that it would be better to examine the alteration of bone density after starting the therapy in such cases.

About one month after the treatment, bone pain was decreased by half, and about two months later, she did not feel at all any pain at rest. Finally, about three months later, she became able to stand up without any difficulties and perform a light labor. It is noted here there was no special treatment for this subject except for the phosphorus replacement therapy.

Taken together, bone pain was dramatically reduced after phosphorus replacement therapy in an elder female subject with FGF23-related hypophosphatemic osteomalacia.

Conclusion and discussion

In this report, we showed a case of elder female subject with FGF23-related hypophosphatemic osteomalacia. She experienced severe bone pain and fragility fracture very frequently in various parts of the body, but after starting phosphorus replacement therapy for hypophosphatemia, marked beneficial effects were obtained. After the phosphorus replacement therapy, hypophosphatemia was significantly ameliorated which was accompanied by the dramatic reduction of bone pain.

The absorption of phosphorus in renal proximal tubule is one of the most important determinants for serum phosphorus concentration. FGF23 suppresses such absorption of phosphorus in renal proximal tubule reduces, which leads to reduction of serum phosphorous levels. In addition, FGF23 functions to suppress the absorption of phosphorus in intestinal tract. Such suppression of phosphorus absorption leads to the development of hypophosphatemic diseases such as tumor-induced osteomalacia. In general, the resection of the tumor is the best way for tumor-induced osteomalacia, but in this case we failed to identify the localization of tumor even with various kind of evaluation. Even in such situations, however, phosphorus replacement therapy for hypophosphatemia markedly reduced the bone pain. Therefore, even when we fail to identify tumor localization, we should start phosphorus replacement therapy. In addition, only small amounts of calcium phosphate (1.5 g/day) (phosphorus content: 270 mg) were used for this subject in order to avoid the appearance of side effects, but bone pain which we failed to suppress with any treatment was dramatically mitigated by the phosphorus replacement therapy, and we think that the amelioration of hypophosphatemia with this treatment would lead to the prevention of further fracture.

It is well know that bone pain could be due to bone metastasis of various kinds of malignant diseases. Especially, lung cancer, breast cancer and melanoma often bring out bone metastasis. However, she had no symptoms and no findings in CT and PET-CT with which we should suspect that she had lung cancer. In addition, she had no symptom in breast and there was no specific observation with which we should suspect that she had breast cancer. There was no specific findings in peripheral blood test with which we should suspect that she had some hematological disease, although we did not perform bone puncture. Furthermore, there was no specific findings in her skin in the whole body with which we should suspect that she had some disease such as melanoma.

There is a limitation in this study. Hospitalization period of this subject was relatively short (12 days) (August 12–23, 2014) due to the convenience of this subject. In addition, after the reduction of bone pain, this subject denied to have various examination. Therefore, although we confirmed that the reduction of bone pain was closely associated with the amelioration of hypophosphatemia, we failed to examine whether the reduction of bone pain is associated with various objective indicators such as grip strength and bone density. We think we should have performed such examination so that we could more objectively show the benefit of small amounts of phosphorus replacement therapy.

Taken together, we should be aware of the possibility that relatively small amounts of calcium phosphate would be enough to reduce the symptom of bone pain and possibly lead to the prevention of fragility fracture especially in elderly subjects as observed in this subject. We think that the findings in this report would be useful from the clinical point of view.

Abbreviations

WBC:

white blood cell

Neu:

neutrophil

Lymph:

lymphocyte

Mono:

monocyte

Eos:

eosinophil

Baso:

basophil

Mono:

monocyte

RBC:

red blood cell

Hb:

hemoglobin

Ht:

hematocrit

plt:

platelet

TP:

total protein

Alb:

albumin

T-bil:

total bilirubin

AST:

aspartate transaminase

ALT:

alanine transaminase

ɣ-GTP:

gamma-glutamyl transferase

ALP:

alkaline phosphatase

LDH:

lactate dehydrogenase

ChE:

cholinesterase

Cre:

creatinine

BUN:

blood urea nitrogen

UA:

uric acid

CK:

creatine kinase

CRP:

C-reactive protein

PBS:

plasma blood glucose

HbA1c:

hemoglobin A1c

LDL chol:

low density lipoprotein cholesterol

HDL chol:

high density lipoprotein cholesterol

TG:

triglyceride

TSH:

thyroid-stimulating hormone

FT4:

free thyroxine

IgG:

immunoglobulin G

IgA:

immunoglobulin A

IgM:

immunoglobulin M

Na:

sodium

K:

potassium

Cl:

chloride

IP:

phosphorus

Ca:

calcium

EFCa:

fractional excretion of calcium

PTH:

parathyroid hormone

PTHrP:

parathyroid hormone-related protein-C

1,25(OH)2D3

1-25-dihydroxyvitamin D3

25(OH)D:

25-hydrovitamin D

ACTH:

adrenocorticotropic hormone

DHEA-S:

dehydroepiandrosterone sulfate

FGF23:

fibroblast growth factor 23

NTx:

type I collagen cross-linked N-telopeptide

TRACP-5b:

tartrate-resistant acid phosphatase-5b

BAP:

bone-type alkaline phosphatase

ucOC:

undercarboxylated osteocalcin

PINP:

type I procollagen N-terminal propeptide

CEA:

carcinoembryonic antigen

CA19-9:

carbohydrate antigen 19–9

CA125:

cancer antigen 125

SLX:

sialyl lewis x antigen

AFP:

alpha-fetoprotein

SCC:

squamous cell carcinoma

CYFRA:

cytokeratin fragment

ProGRP:

pro gastrin-releasing peptide

Declarations

Authors’ contributions

All authors have contributed significantly and are in agreement with the content of the manuscript. HK is the guarantor of this work and have full access to all data in the study. FT, MH, AT, MN, YF, JS, YH, SI, TK, SK, MS, TM, KK, HK researched data and participated in discussion. FT and HK wrote and reviewed the manuscript. All authors read and approved the final manuscript.

Competing interests

The authors declare that they have no competing interests.

Availability of data and materials

All datasets on which the conclusions of the manuscript rely are presented in the main paper.

Consent for publication

We obtained the consent for publication from this subject.

Ethics approval and consent to participate

All procedures followed were in accordance with the ethical standards of the responsible committee on human experimentation (institutional and national) and with the Helsinki Declaration of 1975, as revised in 2008 (Lingenfelser et al. 1995). In addition, we obtained the consent to participate from this subject.

Funding

The authors declare that there is no funding associated with this manuscript.

Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.

Authors’ Affiliations

(1)
Department of Diabetes, Endocrinology and Metabolism, Kawasaki Medical School

References

  1. Bergwitz C, Collins MT, Kamath RS, Rosenberg AE (2011) Case records of the Massachusetts General Hospital. Case 33-2011. A 56-year-old man with hypophosphatemia. N Engl J Med 365:1625–1635View ArticlePubMedPubMed CentralGoogle Scholar
  2. Chong WH, Molinolo AA, Chen CC, Collins MT (2011) Tumor-induced osteomalacia. Endocr Relat Cancer 18:R53–R77View ArticlePubMedPubMed CentralGoogle Scholar
  3. Chong WH, Andreopoulou P, Chen CC, Reynolds J, Guthrie L, Kelly M, Gafni RI, Bhattacharyya N, Boyce AM, El-Maouche D, Crespo DO, Sherry R, Chang R, Wodajo FM, Kletter GB, Dwyer A, Collins MT (2013) Tumor localization and biochemical response to cure in tumor-induced osteomalacia. J Bone Miner Res 28:1386–1398View ArticlePubMedPubMed CentralGoogle Scholar
  4. Jonsson KB, Zahradnik R, Larsson T, White KE, Sugimoto T, Imanishi Y, Yamamoto T, Hampson G, Koshiyama H, Ljunggren O, Oba K, Yang IM, Miyauchi A, Econs MJ, Lavigne J, Jüppner H (2003) Fibroblast growth factor 23 in oncogenic osteomalacia and X-linked hypophosphatemia. N Engl J Med 348:1656–1663View ArticlePubMedGoogle Scholar
  5. Yu X, White KE (2005) FGF23 and disorders of phosphate homeostasis. Cytokine Growth Factor Rev 16:221–232View ArticlePubMedGoogle Scholar
