Open Access

Retinal artery occlusion by left atrial myxoma misdiagnosed as thrombus

  • Jeong-Ho Kim1,
  • Ho-Joong Youn3Email author,
  • Mi-Hyang Jung3,
  • Chang-Yul Oh1,
  • So-Hyun Ahn1,
  • Woo-Hyun Cho1,
  • Jong-Hun Lee1,
  • Yong-Seok Lee1 and
  • Hyo Jin Hyun2
SpringerPlus20165:352

https://doi.org/10.1186/s40064-016-1990-2

Received: 4 February 2016

Accepted: 10 March 2016

Published: 22 March 2016

Abstract

Introduction

Left atrial mass has been known to have a benign course.

Case description

A 55-year-old Asian woman visited to our hospital because of right sided hemiparesis and sudden vision loss in her left eye. She diagnosed as acute cerebral infarction and central retinal artery occlusion by several studies. We detected a large mass in the left atrium and thought this mass as thrombus causing multiple emboli. But her neurologic symptom was aggrevated during therapy and coronary computed tomography angiogram suggested a left atrial myxoma, not thrombus. She underwent the resection of the myxoma.

Discussion and evaluation

Sometimes it could be fatal because it could be source of systemic embolization. Moreover, when the mass is located at unusual site, it is difficult to differentiate thrombus and other benign mass.

Conclusions

We report a patient with a left atrial mass initially presented as multiple embolic infarction. Our case will let ophthalmologists know about the possibility of retinal artery occlusion by cardiac myxoma.

Keywords

Retinal artery occlusionCardiac myxomaThrombusVisual loss

Introduction

Left atrial myxoma, the most common primary cardiac tumor, is usually fatal unless surgically resected (Fintan O’Rourke et al. 2003). The classic echocardiographic features of a left atrial myxoma include a mobile smooth mass attached to the interatrial septum by a stalk which allows the tumor to prolapse into the left ventricle during diastole. However, a definitive transthoracic echocardiographic diagnosis of a left atrial myxoma is difficult when the mass does not prolapse, the site of origin cannot be identified. We report a patient with multiple recurrent cerebral infarction and central retinal artery occlusion, determined to have a left atrial mass simulating a thrombus by transthoracic echocardiography at first. A left atrial mass delayed diagnosed as atrial myxoma and resulted in left eye’s vision loss although the myxoma was resected.

Case report

A 55-year-old woman who presented to the emergency department reported right sided hemiparesis, sudden vision loss in her left eye. She had history of hypertension. Neurologic examination revealed muscle weakness of the right upper and lower limbs. She was found with visual acuities of 20/25 OD and light perception OS. Intraocular pressure was 16 mmHg OD and 16 mmHg OS. Fundus examination of the left eye showed whitening and opacification of the retina with a cherry-red spot in the fovea. Her electrocardiogram showed a normal sinus rhythm. Laboratory findings showed no abnormalities.

Diffusion weighted magnetic resonance imaging (MRI) demonstrated multiple hyperintense areas in the left basal ganglia, parietotemporal lobe, suggestive of acute embolic infarction (Fig. 1a, b). Fundus examination of the left eye showed that multiple branches of the retinal arteries were occluded (Fig. 2, indicated as arrows). Transthoracic eocardiography revealed a left atrial mass of the diameter 3 × 3 cm containing a slightly mobile mass and unclear site of attachment (Fig. 3a, b). Transthoracic echocardiography exhibited a large mass (3 × 3 cm sized) with wide base, located at right wall of the high left atrium in the vicinity of right upper and lower pulmonary vein.
Fig. 1

Brain diffusion-weighted magnetic resonance imaging. a Multiple embolic infarction in left basal ganglia are seen (arrow). b In parietotemporal lobe (arrow)

Fig. 2

Color fundus photography of the left eye: central retinal artery occlusion; retinal artery attenuation (arrows) and optic disc pallor

Fig. 3

Transthoracic echocardiographic findings. a Mass with irregular margin in the left atrium and unclear site of attachment (in four chamber view), b (in subcostal view). LA left atrium, RA right atrium, LV left ventricle, RV right ventricle

At first we thought this mass as thrombus causing multiple emboli. So she was treated with the unfractionated heparin and we planned to recheck the size of mass in the left atrium after 7 days. Five days since admitted, she suddenly fell down and complained aggrevated weakness of the right limbs. We rechecked transthoracic echocardiography and coronary computed tomography angiogram (Fig. 4). Followed transthoracic echocardiography demonstrated no interval change regarding size of mass, further coronary computed tomography angiogram showed the mass had broad stalk from the atrial septum. Therefore, we diagnosed the patient with multiple, recurrent cerebral embolism and retinal artery occlusion due to a left atrial myxoma.
Fig. 4

Coronary computed tomography angiogram. Large mass is located in the left atrium and appears heterogeneously low attenuating. The point of attachment appears to be the interatrial septum

To prevent recurrence, we decided to resect the mass and immediately transferred her to a tertiary hospital. She underwent the resection of the myxoma in a teritary hospital. Microscopic analysis of surgical specimens confirmed that it was the atrial myxoma attached to the atrial septum. The patient uneventfully recovered from cardiac surgery, but unfortunately her left eyesight did not come back. Followed fundus examination of the left eye demonstrated optic disc atrophy and chronic ischemic signs (Fig. 5).
Fig. 5

Followed color fundus photography of the left eye: multiple fibrous changes on retina and choroid

Written informed consent was obtained from the patient for publication of this case report and any accompanying images (IRB File No. 0749-160120-HR-022-01).

Discussion

Retinal artery occlusion caused by acute ischemia of the retina. It may lead to severe irreversible visual impairment. This condition mostly occurs in patients with high blood pressure, heart disease, diabetes or carotid atherosclerosis in elderly people (Varma et al. 2013). Central retinal artery occlusion (CRAO) can be divided into four different subclasses; (1) Non-arteritic permanenet CRAO (2) Non- arteritic transietn CRAO (3) Non-arteriti CRAO with cilioretinal sparing (4) Arteritic CRAO. The majority of CRAOs are caused by platelet fibrin thrombi and emboli as a result of atherosclerotic disease and account for over two-third of all CRAO cases (Chen and Lee 2008).

A cardiac myxoma seems to be a rare cause of vascular problem in the eye, however, ocular episodes due to emboli of a cardiac tumor have been observed in the literature (Schmidt et al. 2005). Physicians should also be alert that myxoma may cause multiple embolic problems, including central retinal arteries occlusion. But we misdiagnosed the cardiac mass as thrombus through transthoracic echocardiography because of unusual attached site and morphology. Mostly cardiac myxoma is attached by a pedicle to the fossa ovalis in the atrial septum but in this case the attached site of the mass get confused at first.

On the contrary to this case, thrombus mimicking cardiac tumors in the atrium have been published (Kmetzo et al. 1985). It means difficult to differentiate between tumors and thrombus. In cases like the present where there is no high risk factor for cerebrovascular disorders or atrial fibrillation, it is important to consider the possibility of myxoma as a cause of multiple embolism despite its rarity. And it demonstrates the utility of transesophageal echocardiography or computed tomography angiogram in distinguishing myxoma from thrombus, if there is not typical features in transthoracic echocardiography (Obeid et al. 1989; Grebenc et al. 2002). Yu et al. reported a 43 year old woman diagnosed with retinal artery occlusion caused by atrial myxoma (Yu et al. 2014). Exact and rapid treatment of atrial myxoma improved patient’s visual capacity. But in our case, we diagnosed the atrial myxoma lately and clinical result was worse.

Conclusions

We report this case of multiple embolism including central retinal artery occlusion caused by left atrial myxoma that mistook as the cardiac thrombus. Physicians should consider the possibility of myxoma in patient with retinal occlusion and timely management will be beneficial for better outcomes and prognosis. In addition, our report will let ophthalmologists know that cardiac myxoma can cause retinal artery occlusion and proper treatment for myxoma is very important for visual capacity.

Declarations

Authors’ contributions

All authors read and approved the final manuscript.

Acknowledgements

We are grateful to Dr. Byung-Ju Shim for assistance with this case.

Competing interests

The authors declare that they have no competing interests.

Open AccessThis article is distributed under the terms of the Creative Commons Attribution 4.0 International License (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, distribution, and reproduction in any medium, provided you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.

Authors’ Affiliations

(1)
Division of Cardiology, Department of Internal Medicine, Pohang St. Mary’s Hospital
(2)
Department of Ophthalmology, Pohang St. Mary’s Hospital
(3)
Cardiovascular Center, College of Medicine, Seoul St. Mary’s Hospital, The Catholic University of Korea

References

  1. Chen CS, Lee AW (2008) Management of acute central retinal artery occlusion. Nat Clin Pract Neurol 4:376–383View ArticleGoogle Scholar
  2. Grebenc ML et al (2002) Cardiac myxoma: imaging features in 83 patients. Radiographics 22:673–689View ArticleGoogle Scholar
  3. Kmetzo JJ, Peters RW, Plotnick GD et al (1985) Left atrial mass. Thrombus mimicking myxoma. Chest 88:906–907View ArticleGoogle Scholar
  4. O’Rourke F, Dean N, Mouradian S et al (2003) Atrial myxoma as a cause of stroke: case report and discussion. Can Med Assoc Licens 169:1049–1051Google Scholar
  5. Obeid AL, Marvasti M, Parker F, Rosenberg J (1989) Comparison of transthoracic and transesophageal echocardiography in diagnosis of left atrial myxoma. Am J Cardiol 63:1006View ArticleGoogle Scholar
  6. Schmidt D, Hetzel A, Geibel-Zehender A (2005) Retinal arterial occlusion due to embolism suspected cardiac tumors-report on two patients and review of the topic. Eur J Med Res 10:296–304Google Scholar
  7. Varma DD, Cugati S, Lee AW, Chen CS (2013) A review of central retinal artery occlusion. Clin Present Manag Eye 27:688–697Google Scholar
  8. Yu Y, Zhu Y, Dong A, Su Z (2014) Retinal artery occlusion as the manifestation of left atrial myxoma: a case report. BMC Ophthalmol 14:164View ArticleGoogle Scholar
