Solitary hepatic lymphangioma: a one-case report


Hepatic lymphangiomas, malformations of the liver lymphatic system, are extremely rare conditions in adults. A 41-year-old man presented with right upper abdominal pain for 6 months was introduced in this report. Ultrasound (US) and computed tomography (CT) scan demonstrated a giant cystictumor with a pedunculatedextrahepatic growth pattern. Due to diagnostic uncertainty, a partial hepatectomy was performed and pathological results confirmed the diagnosis of solitary hepatic lymphangioma. In this article, we reviewed the clinical and pathology features, preoperative diagnostic challenges, and treatments of hepaticlymphangiomas.


Lymphangiomas are benign neoplasms regarded as congenital malformations of the lymphatic system (Stavropoulos et al. 1994). Most lymphangiomas are located in the head, neck, and axilla, where the loose connective tissue allows for easy expansion of lymphatic channels. Intraabdominal cases account for less than 5% of all lymphangiomas (Losanoff et al. 2003). Hepatic Lymphangiomas are characterized by cystic dilatation of the lymphatic vessels in the hepatic parenchyma usually observed in children and adolescents (Bertino et al. 2014; Asch et al. 1974; Zhang et al. 2013). In most cases, the hepatic lesion is usually part of multi-organ involvement including the spleen, kidney, skeleton, gastrointestinal tract, mesentery, lung, pleura, pericardium and other tissues (Stavropoulos et al. 1994; Koh & Sheu 2000). A solitary hepatic lymphangioma in an adult is extremely rare and lack of specific clinical symptoms, therefore, it is easy to be misdiagnosed. The aim of this report is to introducing the experience in managing an adult with a giant liver cystic lymphangioma.

Case report

A 41-year-old male with a 6-month history of left upper abdominal pain visited our department. A large, palpable soft mass 8 cm below the left costal margin was found.

Hematology and biochemistry results were normal while Hepatitis B surface antibody (HBsAb) and Hepatitis B core antibody (HBcAb) were positive. Results of kidney function, electrolytes, and all tumor markers related to the liver were negative. Brain computed tomography (CT) scan and chest X-ray did not find other lesions in the patient.

Abdominal ultrasound (US) showed a giant mixed-echoic mass (15 cm × 10 cm) with a pedunculatedextrahepatic growth pattern. An enhanced abdominal CT scan confirmed a giant cystic hepatic lesion with no capsule. The lesion was demonstrated with a heterogeneous enhancement in the arterial phase (Figure 1). The laboratory and image findings were not sufficient to differentiate the benign or malignant nature of the mass.

Figure 1
figure 1

Contrast-enhanced CT scan shows heterogeneous enhancement of the giant cystic lesion. A) the plain CT scan, B) the arterial phase of CT, C) the portal venous phase of CT, D) CT scan in the sagittal plane. Arrows indicate the hepatic lesion.

At laparotomy, a huge, smooth tumor was found in segment II with pedunculated extrahepatic growth, with no other pathology found in the abdomen. The tumor was completely removed bylocal resectionof segment II of the liver using an ultrasonic scalpel and cavitron ultrasonic surgical aspirator after occlusion of the left hemihepatic vascular.

Histology of the resected specimen revealed a giant cystic mass about 16.2 cm × 13 cm × 4.3cmm in size. On macroscopic examination, the tumor was cystic and multilocular. The cyst had a thick, gray-white wall and was filled with serous fluid containing a small amount of blood. Microscopically, the tumor was composed of irregular and expanded lymphatic vessels, lined by flattened endothelial cells (Figure 2). Immunohistochemical study was carried out on formalin-fixed, paraffin-embedded tissues. The endothelial-like cells were almost all positive for CK18, and pCEA, while Hep-1, HBsAg, CK19, CD34, HBcAg, β-catenin, MUC-1, MAT1, GLy-3, and KIAA were all negative. The final histopathologic diagnosis for the specimen was solitary hepatic lymphangioma.

Figure 2
figure 2

Microscopically, the lesion is composed of anastomosing lymphatic spaces lined by attenuated endothelial-like cells with mature differentiation and containing homogeneous pink fluid.

The postoperative course was uneventful and the patient has been followed up for 30 months. Now, he is symptom-free with no evidence of recurrence on subsequent abdominal imaging.


Lymphangiomas are a group of benign tumors which are composed of lymphatic spaces lined by attenuated endothelium. Histologically, lymphangiomascan be divided into three groups: capillary, cavernous, and cystic lymphangioma (Asch et al. 1974). The exact pathogenesis of lymphangioma remains largely unknown, although the congenital developmental abnormality of the lymphatic tissue, dilatation of abnormal channels, and localized lymphatic obstruction are thought to be the important causes (Asch et al. 1974; Enzinger & Weiss 1995). Other pathogeneses discussed include trauma, inflammatory and fibrotic processes, as well as vascular endothelial permeability disorders. Lymphangiomas are usually found in the neck, axilla, mediastinum, retroperitoneal, soft tissues or other areas rich in lymphoid tissue (Losanoff et al. 2003). Abdominal lymphangiomas, especially solitary ones in one lobe of the liver are extremely rare (Losanoff et al. 2003; Bertino et al. 2014; Koh & Sheu 2000). Hepatic lymphangiomas are characterized by cystic dilatation of the lymphatic vessels in the hepatic parenchyma (Zhang et al. 2013; Conlon et al. 1996) filled withlymph fluid (Enzinger & Weiss 1988).

Hepatic lymphangiomas usually have non-specific clinical signs or symptoms (Matsumoto et al. 2010; Allen et al. 2006). In our case, the main complaint of patient was left upper abdominal pain, which may be related to the expansion of the giant lesion compressing the surrounding structures. Laboratory and Imaging results were of limited use for the preoperative diagnosis of lymphangioma. Because all tumor markers related to the liver were negative, the possibility of hepatocellualar carcinoma and intrahepatic cholangiocarcinoma was relative low (Malaguarnera et al. 2013; Biondi et al. 2012; Bertino et al. 2012). On US, CT, and Magnetic Resonance (MRI), hepatic lymphangioma may appear as a cystic or multi-cystic mass with internal septations, and it is difficult to differentiate it from other cystic disease such as bile duct cyst, biliary cystadenoma and cystadenocarcinoma, or hepatic hydatidosis (Levy et al. 2004), despite the fact that MRI is very helpful in differentiating lymphangioma from a true solid tumor (Siegel et al. 1989). In the patient, the lack of specificity of these preoperative investigations and the rarity of hepatic lymphangioma made it very challengeable to give the accurate preoperative diagnosis. Pathological examinations have been suggested as the only way to identify the nature of the hepatic mass (Steenbergen et al. 1985). We did not perform percutaneous biopsy considering the low positive rate, the risk of bleeding and malignant seeding. The treatment for hepatic lymphangioma is complete resection. Incomplete removal often leads to the recurrence of the cyst (Roisman et al. 1989). Resection is often required for symptom control and accurate diagnosis. Patients with giant hepatic lymphangiomas that are not resectable or with severe impairment of liver function can be treated by orthotopic liver transplantation (Tepetes et al. 1995). The prognoses following surgical treatment are excellent. Alternative therapies for patients who are not suitable for surgical treatment include injection of ethanol or OK-432 (Banieghbal et al. 2003) directly into the lymphangiomas (Steenbergen et al. 1985), but an exact diagnosis is not possible in this way and the psychological impact of the tumor would not be eliminated. In practice, physicians should follow the principles of evidence-based medicine and combine the patient’s wishes with the previous treatment experience to choose the optimal treatment.


In conclusion, we report a rare case of huge hepatic lymphangioma with pedunculatedextrahepatic growth in a 41-year-old male. Preoperative examinations were not sufficient to differentiate the nature of the tumor. The total resection of the tumor resolved all his symptoms, and the pathological finding revealed the true nature of the mass. The long-term prognosis following surgery is quite satisfactory.

Consent statement

Written informed consent was obtained from the patient for publication of this case report and any accompanying images. A copy of the written consent is available for review by the Editor of this journal.

Authors' information

The corresponding author is the deputy head of the Society of hepatobiliary surgery, Branch Association of surgery, China Medical Association. Eastern Hepatobiliary Surgery Hospital is the biggest therapeutic centre of hepatobiliary surgery in China.



Hepatitis B surface antibody


Hepatitis B core antibody


Computed tomography


Magnetic resonance.


  • Allen JG, Riall TS, Cameron JL, Askin FB, Hruban RH, Campbell KA: Abdominal lymphangiomas in adults. J Gastrointest Surg 2006, 10: 746-751. 10.1016/j.gassur.2005.10.015

    Article  Google Scholar

  • Asch MJ, Cohen AH, Moore TC: Hepatic and splenic lymphangiomatosis with skeletal involvement: report of a case and review of the literature. Surgery 1974, 76: 334-339.

    Google Scholar

  • Banieghbal B, Davies MR, et al.: Guidelines for the successful treatment of lymphangioma with OK-432. Eur J Pediatr Surg 2003, 13: 103-107.

    Article  Google Scholar

  • Bertino G, Ardiri A, Malaguarnera M, Malaguarnera G, Bertino N, Calvagno GS: Hepatocellualar carcinoma serum markers. Semin Oncol 2012, 39(4):410-433. 10.1053/j.seminoncol.2012.05.001

    Article  Google Scholar

  • Bertino G, Ardiri A, Demma S, Giuseppecalvagno S, Toro A, Basile E, Campagna D, Ferraro G, Frazzetto E, Proiti M, Malaguarnera G, Bertino N, Malaguarnera M, Malaguarnera M, Amaradio MD, Pricoco G, Di Carlo I: Rare Benign Tumors of the Liver: Still Rare? J Gastrointest Cancer 2014. Feb 9

    Google Scholar

  • Biondi A, Malaguarnera G, Vacante M, Berretta M, D'Agata V, Malaguarnera M, Basile F, Drago F, Bertino G: Elevated serum levels of Chromogranin A in hepatocellular carcinoma. BMC Surg 2012, 12(Suppl 1):S7. 10.1186/1471-2482-12-S1-S7

    Article  Google Scholar

  • Conlon KC, Rusch VW, Gillern S: Laparoscopy: an important tool in the staging of malignant pleural mesothelioma. Ann Surg Oncol 1996, 3: 489-494. 10.1007/BF02305768

    Article  Google Scholar

  • Enzinger FM, Weiss SW: Soft tissue tumours. 2nd edition. Mosby, St-Louis; 1988:614-637.

    Google Scholar

  • Enzinger FM, Weiss SW: Soft Tissue Tumour. 3rd edition. Mosby, St. Louis; 1995:679-700.

    Google Scholar

  • Koh CC, Sheu JC: Hepatic lymphangioma: a case report. Pediatr Surg Int 2000, 16: 515-516. 10.1007/s003839900327

    Article  Google Scholar

  • Levy AD, Cantisani V, Miettinen M: Abdominal lymphangiomas: imaging features with pathologic correlation. Am J Roentgenol 2004, 182: 1485-1491. 10.2214/ajr.182.6.1821485

    Article  Google Scholar

  • Losanoff JE, Richman BW, El-Sherif A, Rider KD, Jones JW: Mesenteric cystic lymphangioma. J Am Coll Surg 2003, 196: 598-603. 10.1016/S1072-7515(02)01755-6

    Article  Google Scholar

  • Malaguarnera G, Paladina I, Giordano M, Malaguarnera M, Bertino G, Berretta M: Serum markers of intrahepatic cholangiocarcinoma. Dis Markers 2013, 34(4):219-228. 10.1155/2013/196412

    Article  Google Scholar

  • Matsumoto T, Ojima H, Akishima-Fukasawa Y, Hiraoka N, Onaya H, Shimada K, Mizuguchi Y, Sakurai S, Ishii T, Kosuge T, Kanai Y: Solitary hepatic lymphangioma: report of a case. Surg Today 2010, 40(9):883-889. 10.1007/s00595-010-4255-7

    Article  Google Scholar

  • Roisman I, Manny J, Fields S, Shiloni E: Intra-abdominal lymphangioma. Br J Surg 1989, 76: 485-489. 10.1002/bjs.1800760519

    Article  Google Scholar

  • Siegel MJ, Glazer HS, St Amour TE, Rosenthal DD: Lymphangiomas in children: MR imaging. Radiology 1989, 170: 467-470.

    Article  Google Scholar

  • Stavropoulos M, Vagianos C, Scopa CD, Dragotis C, Androulakis J: Solitary hepatic lymphangioma a rare benign tumour: a case report. HPB Surg 1994, 8: 33-36. 10.1155/1994/63638

    Article  Google Scholar

  • Steenbergen WV, Joosten E, Marchal G, Baert A, Vanstapel MJ, Desmet V, Wijnants P, De Groote J: Hepatic lympangiomatosis. Report of a case and review of the literature. Gastroenterology 1985, 88: 1968-1972.

    Google Scholar

  • Tepetes K, Selby R, Webb M: Orthotopic liver transplantation for benign hepatic neoplasms. Arch Surg 1995, 130: 153-156. 10.1001/archsurg.1995.01430020043005

    Article  Google Scholar

  • Zhang YZ, Ye YS, Tian L, Li W: Rare case of a solitary huge hepatic cystic lymphangioma. World J Clin Cases 2013, 1(4):152-154. 10.12998/wjcc.v1.i4.152

    Article  Google Scholar

Download references

Author information

Authors and Affiliations


Corresponding author

Correspondence to Jia-Mei Yang.

Additional information

Competing interests

This paper has not been published elsewhere in whole or in part. All authors have read and approved the content, and agreed to submit for consideration for publication in the journal. There are no any financial competing interests or non-financial competing interests. There are no any ethical/legal conflicts involved in the article.

Authors' contributions

Liu Q, Sui CJ performed the operation and drafted the manuscript. Li BS, Gao A, Lu JY participated the treatment of the patient and carried out the follow up study. Yang JM was in charge of the operation. All authors read and approved the final manuscript.

Qu Liu, Cheng-Jun Sui, Bao-Shan Li contributed equally to this work.
