- Open Access
Hippocampal cellular loss after brief hypotension
SpringerPlus volume 2, Article number: 23 (2013)
Brief episodes of hypotension have been shown to cause acute brain damage inanimal models. We used a rat hemorrhagic shock model to assess functionaloutcome and to measure the relative neuronal damage at 1, 4 and 14 dayspost-injury (3 min of hypotension). All rats underwent a neurological assessmentincluding motor abilities, sensory system evaluation and retrograde memory atpost-hypotensive insult. Brains were harvested and stained for Fluorojade C andNissl. Stereology was used to analyze Fluorojade C and Nissl stained brainsections to quantitatively detect neuronal damage after the hypotensive insult.Statistical analysis was performed using Graphpad Prism 5 with the Bonferronitest at a 95% confidence interval after ANOVA. A Mixed Effect Model was usedfor the passive avoidance evaluation. Stereologically counted fluorojadepositive cells in the hippocampus revealed significant differences in neuronalcell injury between control rats and rats that received 3 min of hypotension oneday after insult. Quantification of Nissl positive neuronal cells showed asignificant decrease in the number hippocampal cells at day 14. No changes infrontal cortical cells were evident at any time, no significative changes inneurological assessments as well. Our observations show that brief periods ofhemorrhage-induced hypotension actually result in neuronal cell damage inSprague–Dawley rats even if the extent of neuronal damage that wasincurred was not significant enough to cause changes in motor or sensorybehavior.
Maintenance of adequate blood flow to the brain is necessary in the course of generalanesthesia in order to assure safe recovery and normal brain function after surgicalintervention (Rubio et al. 2008; Moritz et al. 2007). Predictable models of neuronal loss after progressive low bloodpressure insults have been developed (Yamauchi et al. 1990 1991) For instance, Yamauchi and colleagues describedselective progressive damage to regions of the brain after two or three minuteepisodes of profound hypotension (low blood pressure, 25 mmHg) one week after thehypotensive insult (Yamauchi et al. 1990 1991). These changes were attributed to neuronal necrosis(Fukuda and Warner 2007). However, this study did not measurefunctional behavior after recovery from hypotension. Cognitive dysfunction has beenlinked with hypotension (Duschek et al. 2007 Wharton et al.2006), especially in elderly patients (Zuccala et al.2001; Qiu et al. 2005). Severalstudies have studied the relationship between hypotension during surgery andneurological performance after surgery but so far a clear link has not been found(Williams-Russo et al. 1999). The largest study thatevaluated this matter was “The International Study of Postoperative CognitiveDysfunction” but no association between surgical blood pressure andpostoperative cognitive function was found (Moller et al. 1998). In contrast, other researchers have found a link betweenpostoperative cognitive function and blood pressure during surgery (Schutz et al.2006; Yocum et al. 2009).
With this in mind we designed an animal study to test the hypothesis that hypotensiveepisodes during surgery may cause long-term functional alterations. A secondaryobjective of this study was to characterize an animal model of hypotension thatwould produce consistent cerebral damage that could be used for future analyses.
Materials and methods
This study was approved by the division of Comparative Medicine at the Universityof South Florida (USF). All experiments were done following IACUC guidelines.Male Sprague Dawley rats were separated into four groups as follows; groups 1, 2and 3 received 3 min of hypotension - 1 min every hour - and were evaluated at1, 4 and 14 days, respectively. An additional group of rats, group 4, received asham operation (Table 1).
Male Sprague Dawley rats aged between 60 and 90 days with weights between 250 and350g from Harlan Laboratories (Indianapolis, IN) were used. Upon arrival to theUSF College of Medicine Vivarium, rats were housed in a climate controlled roomin plastic cages in groups of two with free access to water and food and wereleft in quarantine for one week before the experiment took place.
The Neurological state of the rat was assessed using the forty-eight point scale(Yokoo et al. 2004). The test was done at 2 differenttime points. The first evaluation was the day before surgery to assure that allrats were neurologically intact. Any rat that demonstrated a neurologicaldeficit was not used for the study. No rats were withdrawn from the study underthose criteria. The second evaluation was completed before tissue collection.The passive avoidance test was used in order to evaluate memory functionfollowing hypotension as described by Saporta (1999).Habituation is the first step. The animal was placed on a platform in aplexiglass box. The amount of time that the rat remained on the platform beforethey stepped down was measured. The following day, the rats were placed on theplatform and received an electric shock (0.5 mA) for three seconds if theystepped down from the platform. After habituation and training, the rats learnedto remain on the platform to avoid being shocked. All rats were trained beforethe hypotensive insult and were tested on the day before and the day ofeuthanasia. For all instances, the animal was placed on the platform and time tostep-down was measured for a maximum of 5 min (300 seconds). Latencies greaterthan 300 seconds were assigned a default value of 300 seconds.
After the weight was recorded, the animal was anesthetized in an inductionchamber with 5% Isoflurane in 100% Oxygen. After the rat was fullyanesthetized we changed the animal from the induction chamber to a mask with 1to 2% Isoflurane in 100% oxygen. The rats were continuously anesthetizedduring the three episodes of hypotension.
After shaving the neck, the area was cleaned with iodine and a medial linearincision was made. Plastic catheters were inserted in the jugular vein and bothcarotid arteries. The arterial lines were used for blood pressure quantificationand blood aspiration. The venous line was used for blood reinfusion. The bloodwas rapidly aspirated until the mean arterial pressure (MAP) reached a point ator below 20 mmHg. The blood was withdrawn and reinfuse is between 10 to 20seconds and the amount range was between 8 to 15 cc. The goal was not to reducethe circulating blood in an specific amount but achieve a blood pressure closeto 20 mmHG. If the animal did not reach a MAP below 20 at any of the 3 episodes;it was excluded from the experiment. When MAP was below 20, the chronometer wasset for 60 seconds. Between 8 cc to 15 cc of blood were taken to reach MAP of 20or less. After the minute, the blood was reinfused using the venous catheter.During the procedure the rats were placed on a heated pad to preventhypothermia. At the end of the third hypotensive episode the catheters wereremoved and skin was closed with a skin stapler. The rats recovered in a cleancage.
The following variables were measured: Weight, temperature (measured with arectal thermometer), hemoglobin saturation (Hb Sat), measured with a pulseoximeter, heart rate (HR), and blood pressure (BP) (obtained directly from anarterial catheter placed in the carotid artery) (SurgiVet Advisor Monitor, modelnumber 92V303100 was used for Hb Sat, HR and BP). Readings were made before andafter each ischemic event. Weight was measured right before the surgery and ateuthanasia.
Brain extraction and sectioning
The rats were euthanatized with an overdose of CO2 and the arterialtree was perfused with normal saline solution 0.9% followed by 4%paraformaldehyde. The brains were harvested, stored in plastic tubes with 4%paraformaldehyde for 24 hours, and then changed to 10%, 20% and 30%sucrose every 24 hours. The brains were sectioned at 40 μm with cryostat HM550 from MICROM International, at a chamber temperature set at −22°C.A series of 5 coronal sections spaced approximately 960 microns apart weremounted for histopathology analysis and stained with Fluorojade C and Nissl. Thebrains were sectioned at 40 μm, the consecutive sections were collected ina 24 well plate previously fill out with PBS + azyde. The sectionscollected from wells # 1 and 13 were stain and mount on glass slides forcounting. We used stereology (optical dissector) to count cells in frontalcortex and CA1 area of hypocampus.
Fluoro jade C
Fluoro Jade C stain is commonly used in ischemia research to label degeneratingneurons regardless of the insult. Fluoro Jade C analysis was used to quantifythe number of degenerating cells in the cortex and CA1 area of the hippocampus;the method used has been described in detail (Ajmo et al. 2008). The sections were mounted on slides and air-dryed overnight;then, they were dipped in absolute ethyl alcohol 3 times, and 1 min in 70%ethyl alcohol and washed in running tap water 1 min, then stained with potassiumpermanganate to oxidize tissue for 15 min while shaking gently. 120 mg ofpotassium permanganate (KMnO4) 0.06% was diluted in 200 mL ofPBS. At this point the slides were protected from light. Staining with FluoroJade C 0.001% for 30 min was followed by 3 changes of water for 1 min andair-dry overnight. The next day under the fume hood, they were cleared in xylenefor 2 min, 3 times. Coverslip with DPX directly from xylene. Fluoro-Jade stockwas made with 0.01% Fluoro Jade C in water (dilute 2 mg/ 20 ml). The workingsolution was made with 0.001% Fluoro-Jade C in 0.1% acetic acid, afterdiluting 20 ml stock with 180 mL of water plus 200 uL of acetic acid.
Nissl is a classic stain used for detection of Nissl bodies in the cytoplasm ofcells, which will be stained purple-blue. Sections were mounted and air-dried ona slide warmer overnight. The following day the slides were dehydrated through100% and 95% alcohol to distilled water. The slides were stained in0.1% cresyl violet solution for 5 min and then rinsed with distilled water.The slides were then immersed in 95% ethyl alcohol for 30 min and posteriordehydrated in 100% alcohol 2 times for 5 min. Under the fume hood they werecleared in xylene for 2 min, 3 times and then immediately coverslipped withDPX.
The data are presented as Mean ± SE. Counting of Fluoro Jade Cpositive cells and Nissl cells was completed using unbiased stereology (Opticalfractionator) as described in by Mouton (2002). For thispurpose a Stereologer from Stereology Resource Center, Chester, Maryland wasused. The results are an estimate of the total number of cells. Neurologicalscore data were also evaluated. One-way Analysis of Variance was followed byBonferroni Multiple Comparison test. The results were analyzed using GraphPadPrism 5.0 for Mac. Passive avoidance was evaluated using a Mixed Effect Model. Ap-value of <0.05 was considered statistically significant.
Results and discussion
We designed the experiment with 40 rats, 7 of which died during surgery. Dead ratswere not replaced (See Table 1). Physiological variables wereconsidered and recorded. The baseline mean arterial pressure combining all thegroups was 100.3 ± 42 mmHg, 94.3 ± 38 mmHg beforethe second insult and 102 ± 40 mmHg before the last insult. Afterthe insult and blood re-infusion the mean arterial pressure was87.7 ± 56.2 mmHg, 94.5 ± 57.2 mmHg and92.7 ± 43.2 mmHg respectively. During the hypotension period, theblood was withdrawn until the MAP reach 20 or less. No statistically significantdifferences were found between the pre-operative values and the post-operativevalues. We also compared the weight before the ischemic event and at day 14 and didnot find any statistically significant change (Table 1). Inpilot studies we have tried 1 or 2 separate minutes of deep hypotension (MAP of 20or less). The first insult that was successful in finding cellular lost was withthree separate minutes of deep hypotension. We believe that accumulation of calciumis a key factor in developing the injury. Future experiments should focus oncounting calcium levels after different number of 1 min insults to corroborate thishypothesis.
Neurological performance was evaluated in all rats. Behavior measurements onpostoperative day 1, 4 and 14 were compared with control; at day one there werepositive findings (unilateral palpebral ptosis). These findings were not present atday 4 or 14. Although there was some neurological impairment 24 hours after theinjury, these changes were not statistically significant. Some rats showed somedegree of paralysis immediately after the surgery but recovered by the time of theneurological evaluation. 10% of the animals showed temporary paralysis of thelower extremities, affected animals recovered in the next 24 hours after surgery. Webelieve that spinal cord ischemia could be the etiology of this finding. One of theanimal models of spinal cord injury is achieved by temporal clipping of the thoracicaorta. We believe that the temporal paralysis that we have seen in some of thisanimals could be related to spinal cord ischemia.
Passive avoidance as described by Saporta (1999), was used totest the ability to recall old memories. During the habituation and training, ratslearned to stay on the platform to avoid an electric shock (Figure 1).
We did not find any memory impairment in the rats after the surgery in comparisonwith the control rats.
Stereology was used to estimate the total number of positive Fluoro Jade C cells inthe frontal cortex and CA1 area of the hippocampus. No significant differences incellular injury represented by numerous fluoro jade positive cortical cells wereseen between control rats and rats that received 3 min of hypotension(p > 0.05). The pictures from Figure 2shown the groups represented in Figure 3B. The first oneis from an animal that received the sham operation, it shows a low number of fluorojade positive cells, in contrast, 24 hours after the insult there is an increase inthe number of cells that are positive for fluoro jade c (positive cells are greenand bright like the one shown with the arrow). This means that since the cells aredamage the stain was able to get into the genetic material. These changes are notnoticeable at day 4 or 14. This can be explained because at this late time pointsthe cells resolved the damage so they are either dead or they recovered from theinjury. For this reason it was important to check for the number of live cells atthis time points. We found congruent results. At day 1 and 4th the number of nisslcells are the same as normal animals but at day 14th the cells have died and thenumber of viable cells has decrease significantly.
On the other hand significant differences in cellular injury were seen betweencontrol rats and rats that received 3 min of hypotension on day one after the insultrepresented by numerous fluoro-jade C positive cells in the CA1 area of thehippocampus (p < 0.05). Figures 3–4. The Nissl stain, stains cells that haveintact genetic materials by the time they where fixed, we can interpret that as"live cells". Fluoro jade C is a stain meant to stain broken genetic material atfixation time, this cells are either dead or degenerating. The tissue collection wasdone at 3 different time points. 1, 4 and 14 days. The cortex did not show anysignificant variations in the number of cells whit any of the dies. We interpretedthis finding as a resistance to the cells to short periods of ischemia due tohypotension. The CA1 area of the hypocampus showed a gradual cellular lostrepresented as a decrease in the number of live cells (Nissl stain) at day 14 incomparison with day 1. This is correlated with the number of fluorojade positivecells that showed an important number of cells affected at day 1. In other words,the cells that were affected at day 1 (fluorojade C) are dead at day 14 for thisreason the number of live cells decreases at day 14 (Nissl stain). This mechanismcould explain why some patients, specially elderly patients show some cognitiveimpairment several days after surgery. The present observations suggest thatexposure to repeated hypotensive episodes lead to hippocampal damage. Patients withhemodynamic TIAs, cerebral arteriosclerotic disease, or orthostatic hypotension mayexperience repeated nonfatal circulatory deficiencies (Yap et al. 2008). Our results suggest that in this rat hemorrhagic model, briefperiods of hypotension result in neuronal damage or distress in the hippocampal CA1region one day after insult. By day 14, surviving cells are significantly reduced inthe hippocampus. We did not find any significant changes in cortical cells. Cellularlost is significant at day 14th and not at day 1 or 4th. We believe that apoptosisis an important factor that is responsible al least in part for this delay cellularlost.
In order to induce a hypotensive state, eight to twelve mL of blood were withdrawn toachieve a mean arterial blood pressure below 20 mmHg. The mean arterial bloodpressure (MAP) for all the groups was 19.2 ± 1.1. Yamauchi(Yamauchi et al. 1990;1991) foundhistopathological changes after one week in the hippocampus of rats with an averageMAP of 25 over a time frame of 2 or 3 min. Our data support the results shown byYamauchi and colleagues and show that hystological damage continues to be presenttwo week after the hypotensive insult.
The forty-eight point neurological scale did not show any statistically significantchanges in motor skills. Interestingly, we found temporal paralysis in the upperbody that lasted a few hours. At the time of the neurological evaluation, theparalysis had disappeared and could not be recorded as a positive finding. Althoughstatistically insignificant, we found that after 24 hours of recovery several ratsdemonstrated palpebral ptosis. By day 4, all rats that had palpebral ptosisrecovered. The dissection of the internal carotid artery typically manifests as anoculo-sympathetic palsy (myosis and palpebral ptosis) in humans (Eschmann et al.2006). We placed the catheters in the common carotidartery but since the surgical area is small, it is possible that we had manipulatedthe internal carotid artery leading to this finding.
The passive avoidance paradigm has been used for memory evaluation. Bekker et al.(2009) used this paradigm in nitroglycerine-inducedhypotensive and showed disruption in consolidation of long-term memory. In thepresent study we did not find any memory alterations. We hypothesize that thisdisparity is due to differences with the methods used to induce hypotension, as weused a hemorrhagic model to induce hypotension and Bekker and colleagues usednitroglycerine. Another difference between our studies is the time of hypotension.Bekker caused the hypotension early after the learning with the latest injection ofnitroglycerine given 3 hours after the training. Our learning regimen took place 24hours before hypotension and was tested twenty-four hours after hypotension. Thisstudy demonstrated that although there is damage in the hippocampus after 3 separateperiods of profound hypotension, memories that are already consolidated were notaffected.
Our conclusions suggest that accidental cerebral blood circulation impairment, whichmay happen for example during surgical procedure with general procedure with generalanesthesia in humans, needs to be considered carefully even in the absence ofclearly evidenced functional signs of neurological damage.
Ajmo CT Jr, Vernon DO, Collier L, Hall AA, Garbuzova-Davis S, Willing A, Pennypacker KR: The spleen contributes to stroke-induced neurodegeneration. J Neurosci Res 2008, 86: 2227-34. 10.1002/jnr.21661
Bekker A, Haile M, Li YS, Galoyan S, Garcia E, Quartermain D, Kamer A, Blanck T: Nimodipine prevents memory impairment caused by nitroglycerin-inducedhypotension in adult mice. Anesth Analg 2009, 109: 1943-8. 10.1213/ANE.0b013e3181beeb3b
Duschek S, Schandry R: Reduced brain perfusion and cognitive performance due to constitutionalhypotension. Clin Auton Res 2007, 17: 69-76. 10.1007/s10286-006-0379-7
Eschmann L, Favrat B, Botez S, Wuerzner K: Partial Horner's syndrome and facial pain: a diagnosis one should notmiss. Rev Med Suisse 2006, 2: 544-6.
Fukuda S, Warner DS: Cerebral protection. Br J Anaesth 2007, 99: 10-7. 10.1093/bja/aem140
Moller JT, Cluitmans P, Rasmussen LS, Houx P, Rasmussen H, Canet J, Rabbitt P, Jolles J, Larsen K, Hanning CD, Langeron O, Johnson T, Lauven PM, Kristensen PA, Biedler A, van Beem H, Fraidakis O, Silverstein JH, Beneken JE, Gravenstein JS: Long-term postoperative cognitive dysfunction in the elderly ISPOCD1 study.ISPOCD investigators. International Study of Post-Operative CognitiveDysfunction. Lancet 1998, 351: 857-61. http://www.sciencedirect.com/science/article/pii/S0140673697073820 10.1016/S0140-6736(97)07382-0
Moritz A, Koci G, Steinlechner B, Holzenbein T, Nasel C, Grubhofer G, Dworschak M: Contralateral stroke during carotid endarterectomy due to abnormalities inthe circle of Willis. Wien Klin Wochenschr 2007, 119: 669-73. 10.1007/s00508-007-0837-9
Mouton P, Principles and Practices of Unbiased Stereology: An Introduction for Bioscientists. 1st edition. The Johns Hopkins University Press, Chester, Maryland; 2002. http://www.amazon.com/Principles-Practices-Unbiased-Stereology-Bioscientists/dp/0801867975#reader_0801867975
Qiu C, Winblad B, Fratiglioni L: The age-dependent relation of blood pressure to cognitive function anddementia. Lancet Neurol 2005, 4: 487-99. http://www.sciencedirect.com/science/article/pii/S1474442205701411 10.1016/S1474-4422(05)70141-1
Rubio A, Hakami L, Munch F, Tandler R, Harig F, Weyand M: Noninvasive control of adequate cerebral oxygenation during low-flowantegrade selective cerebral perfusion on adults and infants in the aorticarch surgery. J Card Surg 2008, 23: 474-9. 10.1111/j.1540-8191.2008.00644.x
Saporta S, Borlongan CV, Sanberg PR: Neural transplantation of human neuroteratocarcinoma (hNT) neurons intoischemic rats. A quantitative dose–response analysis of cell survivaland behavioral recovery. Neuroscience 1999, 91: 519-25. http://www.sciencedirect.com/science/article/pii/S0306452298006101 10.1016/S0306-4522(98)00610-1
Schutz C, Stover JF, Thompson HJ, Hoover RC, Morales DM, Schouten JW, McMillan A, Soltesz K, Motta M, Spangler Z, Neugebauer E, McIntosh TK: Acute, transient hemorrhagic hypotension does not aggravate structural damageor neurologic motor deficits but delays the long-term cognitive recoveryfollowing mild to moderate traumatic brain injury. Crit Care Med 2006, 34: 492-501. http://www.ncbi.nlm.nih.gov/pmc/articles/PMC2377280/ 10.1097/01.CCM.0000198326.32049.7F
Wharton W, Hirshman E, Merritt P, Stangl B, Scanlin K, Krieger L: Lower blood pressure correlates with poorer performance on visuospatialattention tasks in younger individuals. Biol Psychol 2006, 73: 227-34. http://www.sciencedirect.com/science/article/pii/S0301051106001141 10.1016/j.biopsycho.2006.04.002
Williams-Russo P, Sharrock NE, Mattis S, Liguori GA, Mancuso C, Peterson MG, Hollenberg J, Ranawat C, Salvati E, Sculco T: Randomized trial of hypotensive epidural anesthesia in older adults. Anesthesiology 1999, 91: 926-35. http://www.anesthesiaweb.com/protected/lit/rr-00feb-williamsrusso.shtml 10.1097/00000542-199910000-00011
Yamauchi Y, Kato H, Kogure K: Brain damage in a new hemorrhagic shock model in the rat using long-termrecovery. J Cereb Blood Flow Metab 1990, 10: 207-12. 10.1038/jcbfm.1990.36
Yamauchi Y, Kato H, Kogure K: Hippocampal damage following repeated brief hypotensive episodes in therat. J Cereb Blood Flow Metab 1991, 11: 974-8. 10.1038/jcbfm.1991.163
Yap PL, Niti M, Yap KB, Ng TP: Orthostatic hypotension, hypotension and cognitive status: early comorbidmarkers of primary dementia? Dement Geriatr Cogn Disord 2008, 26: 239-46. 10.1159/000160955
Yocum GT, Gaudet JG, Teverbaugh LA, Quest DO, McCormick PC, Connolly ES Jr, Heyer EJ: Neurocognitive performance in hypertensive patients after spine surgery. Anesthesiology 2009, 110: 254-61. 10.1097/ALN.0b013e3181942c7a
Yokoo N, Sheng H, Mixco J, Homi HM, Pearlstein RD, Warner DS: Intraischemic nitrous oxide alters neither neurologic nor histologic outcome:a comparison with dizocilpine. Anesth Analg 2004, 99: 896-903. table of contents 10.1213/01.ANE.0000132973.32387.8B
Zuccala G, Onder G, Pedone C, Carosella L, Pahor M, Bernabei R, Cocchi A: Hypotension and cognitive impairment: Selective association in patients withheart failure. Neurology 2001, 57: 1986-92. 10.1212/WNL.57.11.1986
The authors have not competing interests to declare.
REC: takes responsability on the initial study design, analysis and interpretation ofdata, drafting the article. CQ: her authorship credit is based on supervision of theresearch group and acquisition and analysis of data. GB: sustancial contributions tothe study concept, revising the article critically for intellectual content and thefinal approval of the version to be published. DE: authorship credit based onacquisition, she carried out neurological assessment. AR: analysis andinterpretation of data, revising the article and the final approval of the version.DM: analysis and interpretation of data, revising the article critically. AP:analysis and interpretation of data, statistic consultant. EMC: initial studyconcept and design, takes responsibility for the integrity of the work as a whole.All authors read and approved the final manuscript.
About this article
Cite this article
Chaparro, R.E., Quiroga, C., Bosco, G. et al. Hippocampal cellular loss after brief hypotension. SpringerPlus 2, 23 (2013) doi:10.1186/2193-1801-2-23
- Hemorrhagic shock model
- Neuronal damage
